Performance and Engineering Specifications of the RIPPA R15 ECO

The RIPPA R15 ECO is a state-of-the-art ultra-compact excavator designed to deliver exceptional power and efficiency in confined workspaces. At the heart of this machine is a high-performance Kubota D722 water-cooled diesel engine, which provides a maximum output of 13.9 ps and 10.2 kW at 2500 rpm. This robust powertrain allows the excavator to achieve a maximum digging force of 10.4 KN, making it highly capable of handling demanding excavation tasks despite its small footprint. The hydraulic system is equally impressive, featuring a gear pump with a maximum flow of 21.6 L/min and a 9-way pilot multi-way valve that ensures smooth and precise operation across all functions.

Efficiency and versatility are further enhanced by the machine's advanced hydraulic architecture and mobility features. The R15 ECO boasts a maximum digging depth of 1807 mm and a digging radius of 3274 mm, providing a wide range of motion for various job site requirements. For maneuvering through narrow passages, the excavator is equipped with a hydraulically adjustable track width that can be reduced to 900 mm in seconds and expanded to 1200 mm for increased stability during operation. Additionally, the dual-speed travel system allows for flexible movement speeds ranging from 1.5 to 2.5 km/h, enabling operators to adapt quickly to different terrain conditions.

Advanced Safety Features and Operator Comfort

Safety is a paramount consideration in the design of the RIPPA R15 ECO, which incorporates numerous protective measures for the operator. The machine features a ROPS/FOPS dual-certified frame that offers high compressive strength and protection against falling objects. For visibility during low-light or night operations, the excavator is fitted with bright, boom-mounted LED work lights that provide optimal illumination of the working area. To further safeguard the operator, the cabin can be equipped with a protective net to block debris and a magnetic safety hammer integrated into the seat for emergency escapes. The side lever layout and added protective nets ensure that the driver remains secure and well-positioned during intensive work sessions.

The R15 ECO also prioritizes operator comfort to reduce fatigue and improve long-term productivity. The ergonomic cockpit includes adjustable seating designed to support the back, waist, and neck, along with comfortable armrests on both sides of the control box. The control layout is optimized with a "golden triangle" configuration for joysticks and pedals, allowing for intuitive operation without unnecessary strain. For climate control, the optional cab can be outfitted with a heater for cold weather and a fan to enhance air circulation in high temperatures. Furthermore, 3M thermal insulation cotton is applied to the cabin to regulate temperature and reduce noise, ensuring a higher quality driving experience for the operator.
